TROUBLESHOOTING10 - 6
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
Icons in the display of
the D-MAX operator
interface
The icons in the display of the D-MAX operator interface provide
information about system states. These system states are not
necessarily errors; they may also be intended operating states.
Therefore, these icons must be evaluated individually for
troubleshooting to determine whether what seems to be an
error may actually be a normal operating state of the D-MAXE
system.
Icon Status Indicates Possible error remedy
Error messages
[0004] No motor voltage Is the power supply correctly connected to X1?
Note:
Two power supplies must be connected to the
D-MAX Controller!
see
Electrical connection, page 3-6
Is a fuse blown?
See
Fuse replacement, page 10-14
[0006] Power feedback from
motor (motor acting as
generator)
Are external forces acting on the motor?
Eliminate the external forces
Is the motor under heavy load?
This message appears briefly when heavy
loads are being braked.
Check motor and/or cable for damage or short
circuits
n/a Motor at maximum
current
It is normal for this icon to appear briefly while
a motor accelerates.
If the icon appears persistently: Is the actuator
at end of stroke or mechanically blocked?
[0002] No motor detected or no
motor connected
If a motor is connected, check the motor and/
or cable.
[0001] Error display
An error has been
detected on the selected
"device".
Check the voltages
see
Menu 1.a.6.1.1 Power, page 5-11
