TECHNICAL DATA11 - 7
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
Jobs
* It is possible that the sensor being used is already returning a
center signal. In this case, center guiding will be performed.
** On a D-MAXE 3, S3 is connected to both X9/1 and X11/2, and
S4 is connected to both X11/1 and X9/2 and will generally be
referred to as X11/1.
Note:
Because of the possibility of customer-specific programming,
individual jobs cannot be present or cannot be used differently
than listed in the table. Customer-specific software adjustments
of this type are described in the "Supplementary Operating
Instructions" for the D-MAXE system and are included in the
system documentation.
Job Connection Type of Guiding
A S1 X5/1 Edge guiding*
B S2 X5/2 Edge guiding*
C S3 X9/1** Edge guiding*
D S4 X9/2** Edge guiding*
E S1 - S2 X5/1&2
Center guiding or
slave guiding
F S3 - S4 X9/1&2**
Center guiding or
slave guiding
G S1 - S3 X5/1 & X9/1**
Center guiding or
slave guiding
H S2 - S4 X5/2 & X9/2**
Center guiding or
slave guiding
J X5 X5/2 Line center guiding
K X9 X9/2** Line center guiding
L X5 X5/1 Line edge guiding
M X9 X9/1** Line edge guiding
