COMMISSIONING6 - 3
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
7. If the
LineSpeed
parameter is being used, this parameter
must be calibrated.
(see
Menu 1y.5.1.5 Line Speed (X1), page 7-28
)
8. Set the
SC polarity
parameter.
(see
Menu 1y.4.3 SC Polarity, page 7-18
)
9. Set the
SC gain
parameter.
(see
Menu 1y.4.2 SC Gain, page 7-17
)
10. If an encoder or motor encoder is used, it must be
calibrated.
(see
Menus 1y.5.1.7 Encoder (X3), page 7-30
)
11. You can use the F4 key to select the job whose parameters
you want to adjust.
(see
Selection of "Jobs", page 4-16
)
12. If the optional parameters ’OSC’ or ’PIC’ are found in the
selected job, these parameters must first be switched to the
OFF state.
(see also the Operating Instructions "D-MAXE/OSC" or
"D-MAXE/PIC")
13. Set the
Polarity
parameter.(see
Menu 1y.3.y8 Polarity,
page 7-13
)
14. Set the
Gain
parameter.(see
Menu 1y.3.y3 Gain, page 7-7
)
Note:
Instead of steps 13 and 14, an
Auto Setup
can also be
performed.(see
Menu 1y.3.y2 Auto Setup, page 7-6
)
15. If the optional parameters ’OSC’ or ’PIC’ are present, these
parameters must be correctly set. To do this, perform the
commissioning sequence as described in the relevant
Operating Instructions.
16. Steps 11 to 15 must be performed for each job.
17. If the
Remote Control
parameter has been turned off (see
step 4), this parameter must be reset to
ON (see
1y.2
Remote Control, page 7-2
).
