TROUBLESHOOTING 10 - 13
D-MAXE with OI-B/OI-Nwww.maxcessintl.com MI 2-296 1 D
Fehlersuche.fm
Faulty behavior Reason Remedy Reference
The actuator does
not reach the Servo-
Center position in
"Servo-Center" mode.
The polarity for the
Servo-Center
transducer is set
incorrectly.
Reverse the polarity see
Menu 1y.4.3
SC Polarity, page 7-
18
in section
1y.4
Servo-Center
The Servo-Center
transducer is not
receiving a signal.
Check the distance between the Servo-Center
transducer and the measuring point.
WARNING:
It may be necessary to move the actuator to
adjust the Servo-Center transducer. There is
a risk of cutting injuries on the web and
crushing injuries on the actuator.
Do not touch the edges of the material
web.
Perform the adjustment only when the
machine is stopped and protected against
being turned on.
Type: Switching Distance
ISCT-03: about 1mm
ISCT-20: about 1.5mm
ISCT-21: about 2mm
ISCT-22: about 5mm
ISCT-23: about 10mm
