OPERATION4 - 9
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
* It is possible that the sensor being used is already returning a
center signal. In this case, center guiding will be performed.
** On a D-MAXE 3, S3 is connected to both X9/1 and X11/2, and
S4 is connected to both X11/1 and X9/2 and will generally be
referred to as X11/1.
If only the first two places appear in the status line (for example,
3A), the D-MAXE system is on the user level.
Menu levels:Identifies the position of a menu within the
structure
If a letter appears, it identifies the job selected for the display.
Job Connection Type of Guiding
A S1 X5/1 Edge guiding*
B S2 X5/2 Edge guiding*
C S3 X9/1** Edge guiding*
D S4 X9/2** Edge guiding*
E S1 - S2 X5/1&2 center guiding or
slave guiding
F S3 - S4 X9/1&2** center guiding or
slave guiding
G S1 - S3 X5/1 & X9/1** center guiding or
slave guiding
H S2 - S4 X5/2 & X9/2** center guiding or
slave guiding
J X5 X5/2 Line center guiding
K X9 X9/2** Line center guiding
L X5 X5/1 Line edge guiding
M X9 X9/1** Line edge guiding
