6.4 Pattern common function
125
（1）TB_FUNCTION
Start the Touch Probe action, the basic object used for various Settings, and the
corresponding Bit description
bit value Note
0
0 Switch off touch probe 1
1 Enable touch probe 1
1
0 Trigger first event
1 Continuous
2
0 Trigger with touch probe 1 input
1 Trigger with zero impulse signal of position encoder
3 - Reserved
4
0 Switch off sampling at positive edge of touch probe 1
1 Enable sampling at positive edge of touch probe 1
5
0 Switch off sampling at negative edge of touch probe 1
1 Enable sampling at negative edge of touch probe 1
6~7 - Not Supported
8
0 Switch off touch probe 2
1 Enable touch probe 2
9
0 Trigger first event
1 Continuous
10
0 Trigger with touch probe 2 input
1 Trigger with zero impulse signal of position encoder
11 - Reserved
12
0 Switch off sampling at positive edge of touch probe 2
1 Enable sampling at positive edge of touch probe 2
13
0 Switch off sampling at negative edge of touch probe 2
1 Enable sampling at negative edge of touch probe 2
14~15 - Not Supported
 If the Z phase is selected according to the trigger setting, do not select the falling edge.
There is no guarantee that the actions set above will be performed.
 The rising edge represents the time when the theoretical state of the object signal changes
from OFF (inactive state) to ON (active state), and the falling edge represents the time
when the theoretical state of the object signal changes from ON to OFF.
