Chapter 6 Communication function
126
（2）TB_STATUS
Indicates the status of the Touch Probe action. The corresponding Bit is described
bit value Note
0
0 Touch probe 1 is switch off
1 Touch probe 1 is enabled
1
0 Touch probe 1 no positive edge value stored
1 Touch probe 1 positive edge value stored
2
0 Touch probe 1 no negative edge value stored
1 Touch probe 1 negative edge value stored
3~5 - Reserved
6~7 - Not Supported
8
0 Touch probe 2 is switch off
1 Touch probe 2 is enabled
9
0 Touch probe 2 no positive edge value stored
1 Touch probe 2 positive edge value stored
10
0 Touch probe 2 no negative edge value stored
1 Touch probe 2 negative edge value stored
11~13 - Reserved
14~15 - Not Supported
3. Start the Touch probe action
Bit0 /bit8 (Touch Probe execution/stop) of the TB_FUNCTION changes from 0 (stop) to 1
(start), obtains the set conditions (TB_FUNCTION: bit1-7 / BIT9-15), and starts the Touch
Probe. Changes to various Settings are valid, please bit0/bit8 return once to "0 (stop)", and then
again to "1 (start)".
According to the bit1 TB_FUNCTION/combination mode selection (events), you can
choose to "0 (the Trigger First event mode)", "1" (Continuous mode).
 Trigger First Event mode (TB_FUNCTION: bit1=0 / bit9=0).
After starting, only under the trigger signal of the first clamping mode. In order to obtain it
again, it is necessary to start the Touch Probe again.
