BODY STRUCTURE [BODY STRUCTURE]
09-80A–3
09-80A
.
NO. Part Name
Ultra high-tension
steel
High-tension
steel
Rust proof steel
Thickness (mm
{in})
1 Bonnet — ××0.7 {0.03}
2 Front bumper bracket — — — 2.6 {0.10}
3 Shroud side panel — — × 2.0 {0.079}
4 Shroud side member — — × 1.2 {0.047}
5 Wheel apron (front) — — × 0.65 {0.026}
6 Wheel housing (lower) — — × 1.2 {0.047}
7 Wheel housing (upper) — ××2.9 {0.11}
8 Front side frame (inner)
Front × — × 1.6 {0.063}
Rear — ××2.3 {0.091}
9 Front side frame (outer) — ××1.6 {0.063}
10 Apron reinforcement (upper) — — × 1.0 {0.039}
11 Apron reinforcement (lower) — ××1.2 {0.047}
12 Torque box — — × 1.4 {0.055}
13 Front frame reinforcement (rear) — ××2.0 {0.079}
14 Wheel apron reinforcement (front) — — × 1.4 {0.055}
15 Front fender panel — ××0.8 {0.03}
16 Front fender stay — — × 1.4 {0.055}
17 Dash lower panel — — × 0.85 {0.033}
18 Dash lower member — — × 1.6 {0.063}
19 Front pillar reinforcement × — — 1.4 {0.055}
20 Front pillar (inner) × — — 1.6 {0.063}
21 Hinge pillar (inner) × — × 1.2 {0.047}
22 Front pillar reinforcement (upper) × — — 1.6 {0.063}
23 Hinge reinforcement × — × 1.6 {0.063}
24 Cowl side reinforcement — — × 1.2 {0.047}
25 Side sill reinforcement
× — × 1.4 {0.05
5
}
26 Side frame (outer) — — × 0.7 {0.03}
27 Side sill (inner) × — × 1.6 {0.063}
28 Roof rail (inner, rear) × — — 1.4 {0.055}
29 B-pillar (inner) × — × 1.2 {0.047}
30 Roof rail reinforcement × — — 1.6 {0.063}
31 B-pillar reinforcement
Upper × — — 1.6 {0.063}
Center × — — 1.8 {0.071}
Lower × — — 1.2 {0.047}
32 Front door panel (outer) — ××0.7 {0.03}
33 Rear door panel (outer) — ××0.65 {0.026}
34 Bulkhead junction — — — 0.7 {0.03}
35 Rear pillar (inner) — — — 0.65 {0.026}
36 Wheel house (inner) — — × 0.75 {0.030}
37 Side sill reinforcement (rear) — ××1.6 {0.063}
38 Package tray — — — 0.6 {0.02}
39 Rear fender rain rail — — × 0.7 {0.03}
40 Corner plate — — × 0.7 {0.03}
41 Trunk lid panel (outer) — ××0.65 {0.026}
42 Wiper bracket — — × 1.6 {0.063}
43 Dash upper panel — — × 0.9 {0.04}
44 Roof panel — — — 0.75 {0.030}
45 Front header — — — 0.7 {0.03}
46 Roof reinforcement (front) — — — 0.55 {0.022}
47 Roof reinforcement (center) — × — 1.0 {0.039}
48 Roof reinforcement (rear) — — — 0.55 {0.022}
49 Rear header — — — 0.65 {0.026}
50 Front floor pan — — × 0.6 {0.02}
