BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–56
3. Drill the 22 locations indicated by (C) shown in the figure.
4. Remove the B-pillar reinforcement.
(C) 2
(C) 5
(C) 6
(C) 3
(C) 3
(C) 2
B-PILLAR REINFORCEMENT
am6xub0000009
