Meggitt VM600 Hardware Manual

VM600 MPS hardware manual (standard version) MAMPS-HW/E 8 - 15
Edition 17 - February 2018
Installation procedure for cards
INSTALLATION
8.4.2.3 Hot swapping a card in the front of a VM600 rack
The procedure for hot swapping a card in the front of a VM600 rack is as follows.
In the front of the rack:
1- Disconnect the external cables connected to the card, if any.
2- Remove the card from the rack (see 14.6.2 Replacing a suspect card).
3- Insert the replacement card in the front of the rack.
4- Reconnect any cables to the card.
8.4.2.4 Hot swapping a card in the rear of a VM600 rack
The procedure for hot swapping a card in the rear of a VM600 rack is as follows.
First, in the front of the rack:
1- Remove any associated processing card in the corresponding slot in the front of the rack
from the rack’s backplane.
Then, in the rear of the rack:
2- Disconnect all external cables connected to the card.
3- Remove the card from the rear of the rack (see 14.6.2 Replacing a suspect card).
4- Insert the replacement card in the rear of the rack.
5- Reconnect all of the cables to the card.
Finally, in the front of the rack:
6- Reinsert the associated processing card in the corresponding slot in the front of the rack
(to the rack’s backplane).
8.4.2.5 Which card types can be hot swapped?
It is necessary to power down the ABE04x rack before inserting or removing any of the
following elements:
•CPUM
• RPS6U, in racks employing a single power supply.
The following elements have “hot swapping” capability, that is, they can be removed from and
inserted into the MPS rack while it is powered up (a technique sometimes referred to as “live
insertion”):
• MPC4 and its associated IOC4T card (see 8.4.2.6 Hot swapping MPC4 and AMC8
cards, and the IRC4 card)
• AMC8 and its associated IOC8T card (see 8.4.2.6 Hot swapping MPC4 and AMC8
cards, and the IRC4 card)
• RLC16
• RPS6U.
A single RPS6U rack power supply can be replaced in racks employing two such power
supplies to support rack power supply redundancy (see 2.10.5 Racks with two RPS6U
rack power supplies in order to support rack power supply redundancy).
Before “hot swapping” a card in the rear of a VM600 rack, any associated
processing card in the corresponding slots in the front of the rack must be
disconnected from the rack’s backplane.
See 14.6.2 Replacing a suspect card.
