Assigning alarm signals to relays on the IRC4 card
CONFIGURATION OF AMC8 / IOC8T CARDS
10.9Assigning alarm signals to relays on the IRC4 card
Unlike the RLC16 card, the local relays on the IRC4 are configured entirely under software
control, using the IRC4 Configurator software. That is, there are no jumpers that need to be
set on the IRC4 card (see Figure 12-1). Nevertheless the jumpers on the IOC4T card still
need to be configured manually.
The mapping of the OC and Raw buses in the VM600 MPS software is made using an RLC16
card that acts as an IRC4 card in order to create the configuration file (*.rck file). This file,
along with an Excel
®
file (*.xls file) containing the logic equations, is used by the IRC4
Configurator software to map the relays.
Refer to the IRC4 configurator for intelligent relay cards software manual for further
information on how to configure (map) the relays on an IRC4 card.
13
12 - - - - - - J61 J94 J93 - - -
- - - 38 J112 J62 J94 J93 6 High
- - - 46 J128 J63 J94 J93 14 High
- - - 54 J144 J64 J94 J93 22 High
- - - 62 J160 J65 J94 J93 30 High
14
13 - - - - - - J66 J114 J113 - - -
- - - 6 J113 J67 J114 J113 6 Low
- - - 14 J129 J68 J114 J113 14 Low
- - - 22 J145 J69 J114 J113 22 Low
- - - 30 J161 J70 J114 J113 30 Low
15
14 - - - - - - J71 J96 J95 - - -
- - - 39 J114 J72 J96 J95 7 High
- - - 47 J130 J73 J96 J95 15 High
- - - 55 J146 J74 J96 J95 23 High
- - - 63 J162 J75 J96 J95 31 High
16
15 - - - - - - J76 J116 J115 - - -
- - - 7 J115 J77 J116 J115 7 Low
- - - 15 J131 J78 J116 J115 15 Low
- - - 23 J147 J79 J116 J115 23 Low
- - - 31 J163 J80 J116 J115 31 Low
Notes
1. To attribute a Raw Bus line to a relay, the appropriate jumper must have contacts 1-2 closed.
Table 10-2: Jumpers and bus lines associated with relays on RLC16 card (continued)
Line number Jumper settings
Relay
number (on
RLC16)
OC
Bus
Raw
Bus
On IOC8T
(see note 1)
On RLC16
Raw Bus
signal line
used
To select the
relay
To set the
relay NE
To set the
relay NDE
