9 - 42 VM600 MPS hardware manual (standard version) MAMPS-HW/E
Edition 17 - February 2018
Using the Raw Bus to share measurement channel inputs
CONFIGURATION OF MPC4 / IOC4T CARDS
For example, to allocate Raw Bus line pair 7 for use with measurement channel 4 (that is, its
corresponding measurement channel), jumpers J314 and J315 should have contacts 1-3
closed.
Measurement channel 4 15 J330 and J331
Measurement channel 1 16 J332 and J333
Measurement channel 2 17 J334 and J335
Measurement channel 3 18 J336 and J337
Measurement channel 4 19 J338 and J339
Measurement channel 1 20 J340 and J341
Measurement channel 2 21 J342 and J343
Measurement channel 3 22 J344 and J345
Measurement channel 4 23 J346 and J347
Measurement channel 1 24 J348 and J349
Measurement channel 2 25 J350 and J351
Measurement channel 3 26 J352 and J353
Measurement channel 4 27 J354 and J355
Measurement channel 1 28 J356 and J357
Measurement channel 2 29 J358 and J359
Measurement channel 3 30 J360 and J361
Measurement channel 4 31 J362 and J363
Table 9-6: Raw bus lines and jumpers associated with measurement channels
for the MPC4 card (continued)
MPC4 measurement channel
(raw analog signal)
Raw Bus
line pair
IOC4T jumper settings
(contacts 1-3 closed)
