Assigning alarm signals to relays on the RLC16 card
CONFIGURATION OF MPC4 / IOC4T CARDS
12
11 - - - - - - J56 J112 J111 - - -
- - - 5 J311 J57 J112 J111 5 Low
- - - 13 J327 J58 J112 J111 13 Low
- - - 21 J343 J59 J112 J111 21 Low
- - - 29 J359 J60 J112 J111 29 Low
13
12 - - - - - - J61 J94 J93 - - -
- - - 38 J312 J62 J94 J93 6 High
- - - 46 J328 J63 J94 J93 14 High
- - - 54 J344 J64 J94 J93 22 High
- - - 62 J360 J65 J94 J93 30 High
14
13 - - - - - - J66 J114 J113 - - -
- - - 6 J313 J67 J114 J113 6 Low
- - - 14 J329 J68 J114 J113 14 Low
- - - 22 J345 J69 J114 J113 22 Low
- - - 30 J361 J70 J114 J113 30 Low
15
14 - - - - - - J71 J96 J95 - - -
- - - 39 J314 J72 J96 J95 7 High
- - - 47 J330 J73 J96 J95 15 High
- - - 55 J346 J74 J96 J95 23 High
- - - 63 J362 J75 J96 J95 31 High
16
15 - - - - - - J76 J116 J115 - - -
- - - 7 J315 J77 J116 J115 7 Low
- - - 15 J331 J78 J116 J115 15 Low
- - - 23 J347 J79 J116 J115 23 Low
- - - 31 J363 J80 J116 J115 31 Low
Notes
1. To attribute a Raw Bus line to a relay, the appropriate jumper must have contacts 1-2 closed.
2. To obtain a raw signal on a Raw Bus line, the appropriate jumper(s) must have contacts 1-3 closed. For differential signals,
two jumpers must be set. For example, for Raw Bus line 16, set J332 and J333 as they correspond to 16 High and 16 Low
respectively.
Table 9-7: Jumpers and bus lines associated with relays on the RLC16 card (continued)
Line number Jumper settings
Relay
number
(on RLC16)
OC
Bus
Raw
Bus
On IOC4T
(see note 1 and
note 2)
On RLC16 Raw Bus
signal line
used
(see note 2)
To select the
relay
To set the
relay as NE
To set the
relay as NDE
