Meggitt VM600 Hardware Manual

VM600 MPS hardware manual (standard version) MAMPS-HW/E 10 - 25
Edition 17 - February 2018
Assigning alarm signals to relays on the RLC16 card
CONFIGURATION OF AMC8 / IOC8T CARDS
Table 10-2: Jumpers and bus lines associated with relays on RLC16 card
Line number Jumper settings
Relay
number (on
RLC16)
OC
Bus
Raw
Bus
On IOC8T
(see note 1)
On RLC16
Raw Bus
signal line
used
To select the
relay
To set the
relay NE
To set the
relay NDE
1
0 - - - - - - J1 J82 J81 - - -
- - - 32 J100 J2 J82 J81 0 High
- - - 40 J116 J3 J82 J81 8 High
- - - 48 J132 J4 J82 J81 16 High
- - - 56 J148 J5 J82 J81 24 High
2
1 - - - - - - J6 J102 J101 - - -
- - - 0 J101 J7 J102 J101 0 Low
- - - 8 J117 J8 J102 J101 8 Low
- - - 16 J133 J9 J102 J101 16 Low
- - - 24 J149 J10 J102 J101 24 Low
3
2 - - - - - - J11 J84 J83 - - -
- - - 33 J102 J12 J84 J83 1 High
- - - 41 J118 J13 J84 J83 9 High
- - - 49 J134 J14 J84 J83 17 High
- - - 57 J150 J15 J84 J83 25 High
4
3 - - - - - - J16 J104 J103 - - -
- - - 1 J103 J17 J104 J103 1 Low
- - - 9 J119 J18 J104 J103 9 Low
- - - 17 J135 J19 J104 J103 17 Low
- - - 25 J151 J20 J104 J103 25 Low
5
4 - - - - - - J21 J86 J85 - - -
- - - 34 J104 J22 J86 J85 2 High
- - - 42 J120 J23 J86 J85 10 High
- - - 50 J136 J24 J86 J85 18 High
- - - 58 J152 J25 J86 J85 26 High
6
5 - - - - - - J26 J106 J105 - - -
- - - 2 J105 J27 J106 J105 2 Low
- - - 10 J121 J28 J106 J105 10 Low
- - - 18 J137 J29 J106 J105 18 Low
- - - 26 J153 J30 J106 J105 26 Low
