VM600 MPS hardware manual (standard version) MAMPS-HW/E 11 - 3
Edition 17 - February 2018
Definition of screw terminals on the RLC16 card
USING THE RLC16 CARD
Table 11-1: Definition of terminals for J1, J2 and J3 on the RLC16 card
Terminal Name Definition
Connector J1
1 RL1 Relay 1 NC (normally closed) contact
2 RL1 Relay 1 NO (normally open) contact
3 RL1 Relay 1 COM (common) contact
4 RL2 Relay 2 NC
5 RL2 Relay 2 NO
6 RL2 Relay 2 COM
7 RL3 Relay 3 NC
8 RL3 Relay 3 NO
9 RL3 Relay 3 COM
10 RL4 Relay 4 NC
11 RL4 Relay 4 NO
12 RL4 Relay 4 COM
13 RL5 Relay 5 NC
14 RL5 Relay 5 NO
15 RL5 Relay 5 COM
16 RL6 Relay 6 NC
Connector J2
1 RL6 Relay 6 NO
2 RL6 Relay 6 COM
3 RL7 Relay 7 NC
4 RL7 Relay 7 NO
5 RL7 Relay 7 COM
6 RL8 Relay 8 NC
7 RL8 Relay 8 NO
8 RL8 Relay 8 COM
9 RL9 Relay 9 NC
10 RL9 Relay 9 NO
11 RL9 Relay 9 COM
12 RL10 Relay 10 NC
13 RL10 Relay 10 NO
14 RL10 Relay 10 COM
