3 - 10 VM600 MPS hardware manual (standard version) MAMPS-HW/E
Edition 17 - February 2018
VM600 6U 19" rack backplane (ABE04x)
GENERAL SYSTEM DESCRIPTION
Figure 3-5: Schematic of the Tacho Bus
IOC #A IOC #B
Notes
1. Software generated control signal to inhibit the
(de)multiplexer or select the appropriate line.
Control signal
(see note 1)
Control signal
(see note 1)
Control signal
(see note 1)
Control signal
(see note 1)
Control signal
(see note 1)
Control signal
(see note 1)
Control signal
(see note 1)
Control signal
(see note 1)
Demulti
-plexer
Demulti
-plexer
Demulti
-plexer
Demulti
-plexer
Multi-
plexer
Multi-
plexer
Multi-
plexer
Multi-
plexer
TACHO BUS
To MPC #A
To MPC #B
To MPC #A To MPC #BFrom IOC #A From IOC #B
SPEED 1A “REMOTE”
SPEED 2A “REMOTE”
SPEED 1B “REMOTE”
SPEED 2B “REMOTE”
SPEED 1B “LOCAL”
SPEED 2B “LOCAL”
SPEED 1A “LOCAL”
SPEED 2A “LOCAL”
SPEED 1A
SPEED 2A
SPEED 1B
SPEED 2B
