Memotec CX950 User Manual

21 INSTALLATION AND CONFIGURATION
3021M100-002
21-13
1. Determine the kind of I/O card you want to connect to its network device.
2. Determine the kind of cable you need to connect this I/O card to its network
device.
3. Locate the connector on the cable that matches the I/O card’s port connector,
then attach these connectors.
4. Attach the connector at the other end of the cable to the port of the network
device.
5. Repeat steps 1-4 for each I/O card you want to connect to its network device.
Table 21-1 Cables Available from Memotec
Interface Cable Part # Description
V.24 (EIA-232) CBLA0006-010
male DB-25 to male DB-25 (3 m; 10 ft)
with 4-40 screws
V.24 (EIA-232) CBLA0006-110
male DB-25 to male DB-25 (3 m; 10 ft)
with M3 screws
V.35EU CBLA0015-010
male M-34 block to male M-34 block (3
m; 10 ft
Multi V.24 (EIA-232) CBLA0017-024
male DB-60 to 5 female DB-25s (0.6
m; 2 ft)
Multi V.24 (EIA-232) CBLA0017-124
male DB-60 to 5 female DB-25s (0.6
m; 2 ft) with M-3 screws
V.35H CBLA0014-010
male M-34 block to male DB-25 (3 m;
10 ft)
V.35H CBLA-0014-210
male M-34 block to female DB-25 (3
m; 10 ft
X.21 CBLA0005-010 male DB-15 to male DB-26 (3 m; 10 ft)
Universal Serial (V.24) CBLA0027-000 male VHDCI to female DB-25
Universal Serial (V.24) CBLB0002-001 female to male gender changer
Universal Serial (V.35) CBLA0032-000 male DB-25 to male M.34
Universal Serial (V.35) CBLA0032-200 male DB-25 to female M.34
Universal Serial (X.21) CBLA0033-000 male DB-25 to male DB-15
Universal Serial (X.21) CBLA0033-200 male DB-25 to female DB-15
V.24/V.35 (DCE/DTE) CBLA0031-000 adapter for split clocking
RJ-45 CBLB0001-000 adapter RJ-45 to 2 BNC connectors
Voice 60300049
male RJ-12 to male RJ-12, straight-
through (3 m; 10 ft)
Voice (E&M) 60300050
male RJ-45 to male RJ-45, straight-
through (3 m; 10 ft)
Voice (E&M I or V) 60300051
eight male RJ-12 (each carrying six
signals) to one standard 25-pair telco
female connector (to PBX punch
block); octopus (1 m; 40 in)
Voice (E&M II, III or IV) 60300052
six male RJ-45 (each carrying eight
signals) to one standard 25-pair telco
female connector (to PBX punch
block); octopus (1 m; 40 in)
