136 Operating Instructions - CPC6050
Modular Pressure Controller
CPC6050
Following is the list of options and their descriptions:
• Metric: this option changes the barometric pressure reading to show the standard metric value
• High resolution: this option changes the displayed resolution of current pressure reading to 7 signi-
cant digits
• Delta: activates the delta function to allow A+B, A-B, B+A or B-A output when a dual channel instru-
ment is present
• PACE5000 SCPI Emulation: this option allows the selection of SCPI GE command set in the Re-
mote Communication App (Section 6.4.9)
• Purge function: this option enables/ disables the Purge function on respective channels which
drives the Automatic Contamination Prevention System.
Warning
!
WARNING! It is not recommended to activate other software options without consulting
with WIKA/ Mensor Service Centers (Section 10.1)
11.2 Logging
The Logging Application enables real-time storage of current instrument output and state in a
USB device plugged to the front panel of the CPC6050. The application also provides a means
to log any remote communication (commands and responses) to the instrument. The primary
objective of this application is to provide test data for troubleshooting purposes.
i
Note: The Logging Application is only visible when a compatible USB device is plugged to the
front panel of the CPC6050. The Application is greyed out in the absence of a USB device.
Figure 11.2.-A shows the Logging App with and without a USB.
Figure 11.2-A Logging App with USB (left) and without USB (right)
