52 Operating Instructions - CPC6050
Modular Pressure Controller
CPC6050
6.4.4.6 Delta Function
The Delta Channel selection screen has all of the functions of channels A & B, plus an additional function
where delta is dened as either Channel A - Channel B (A-B), or Channel B - Channel A (B-A). The Delta
Screen in the Home App will display a reading resulting from the mathematical equation chosen in this
screen.
Figure 6.4.4.5 - Delta Function
6.4.5 Remote Application
With the Remote Settings application users can select the remote command set for all inter-
faces. The GPIB address, Ethernet network parameters and Serial parameters can also be set
here. Details about the Remote Operation (command sets, cable requirements, etc.) can be
found in Section 7, Remote Operation.
Figure 6.4.5 - Remote Application
