48 Operating Instructions - CPC6050
Modular Pressure Controller
CPC6050
6.4.3.10 Detection Flags
The CPC6050 is equipped with three detection ags (SVR Module only) that can be enabled or disabled
by the user as needed. These detection ags appear in the Control Settings App. The primary purpose
of these detection ags is to protect the instrument and to ensure desired operation. Each of these ags
can be turned “On” or “O” as per user’s need. Figure 6.4.3.10 shows the detection ag settings.
• Supply Detection Enable: If turned “On”, this ag allows the user to check for sucient supply pres-
sure at the Supply Port of the instrument. In case the supply pressure is less than 10% of the control
setpoint, an error is reported which can be seen in the Troubleshoot App by clicking the error symbol
[ ]. This ag is turned “O” by default.
• Burst Detection Enable: If turned “On”, this ag allows the user to protect the instrument against sud-
den bursts in the pressure at the Measure/ Control Port. In case a burst is detected, an error is report-
ed which can be seen in the Troubleshoot App. This ag is turned “On” by default.
• Measure Regulation Enable: If turned “On”, this ag allows pressure to be controlled while the instru-
ment is in “Measure” mode to prevent pressure leaks in the system over time. This will turn on the in-
ternal pressure regulator periodically to control pressure in a certain range of the measured pressure
value. This ag is turned “O” by default.
Detection
Flags
Figure 6.4.3.10 - Detection Flags
