40 Operating Instructions - CPC6050
Modular Pressure Controller
CPC6050
6.4.2.4 User Base Units / Base Units Multiplier
When choosing a unit of measure from the Home Application (main screen), standard units can be cho-
sen in addition to two user dened units. User units 1 and 2 are dened in the Settings App using “User
1 base units”, “User 1 multiplier” and / or “User 2 base units”, “User 2 multiplier”. If the display of a special
unit is needed, then a base unit should be chosen (psi, bar or Pascal) as the “User base unit” and the
“User multiplier” can be entered to derive the special unit using the formula: Special unit = Base Unit x
Unit multiplier. When set this way, and the user unit has been chosen from the main screen, then the user
unit will now display the Special unit as derived.
Figure 6.4.2.4 - User base units / Base units multiplier
6.4.2.5 Barometer Units
When the Barometer Units button has been chosen, a list of Imperial or Metric units is presented on the
right side of the screen. Any of these units can be chosen from this list for the barometric readout. The
barometric pressure readout can be seen on the bottom right of the Home App.
Figure 6.4.2.5 - Barometer units
