4.3 ApprovalsandCerticates
EC declaration of conformity
EMC directive
11)
EN 61326-1 emission (group 1, class A) and interference immunity (industrial application)
Low voltage directive EN 61010-1
RoHS directive 2011/65/EU, article 4
Certicate
Calibration
12)
Standard: A2LA calibration certicate (standard on factory)
Option: DKD/DAkkS calibration certicate
11) Warning! This is class A equipment for emissions and is intended for use in industrial environments. In other environments, e.g. residential or commercial installations, it can intefere with
other equipment under certain conditions. In such circumstances the operator is expected to take the appropriate measures.
12) Calibration in a horizontal position/operating position.
4.4 Working Ranges of the Controller Modules
Bi-directional or gauge pressure [bar (psi)]
1)
-1 (-15) 0 1 (15) 3.4 (50) 10 (150) 100 (1,500) 210 (3,045)
LPPump MODULE ±12.5 mbar (±0.18 psi)
2)
LPSVR MODULE ±12.5 mbar (±0.18 psi)
2)
MPSVR MODULE ±0.35 bar (±5 psi)
2)
HPSVR MODULE -1 ... 5 bar (-15 ... +75 psi)
2)
EPSVR MODULE -1 ... 10 bar (-15 ... +150 psi)
2)
Absolute pressure [bar (psi)]
1)
0 2 (30) 4.4 (65) 11 (165) 101 (1,515) 211 (3,060)
LPPump MODULE 0 ... 0.5 bar (0 ... 7.5 psi)
2)
LPSVR MODULE 0 ... 0.5 bar (0 ... 7.5 psi)
2)
MPSVR MODULE 0 ... 1 bar (0 ... 15 psi)
2)
HPSVR MODULE 0 ... 6 bar (0 ... 90 psi)
2)
EPSVR MODULE 0 ... 11 bar (0 ... 165 psi)
2)
1) Mixing of absolute pressure and gauge pressure transducers in a module is not possible.
2) Smallest acceptable transducer range including turndown ranges.
For controlling absolute pressure a vacuum pump connected at the Exhaust port is required.
