36 Operating Instructions - CPC6050
Modular Pressure Controller
CPC6050
6.4.1.7 Tare Button
If the Tare calibration function has been chosen in the Display Settings App (section 6.4.4), then the Tare
Button [ ] will appear in the channel screen. For safety reasons, the tare button will be highlighted
in yellow when active. The Tare button and the Zero Button cannot appear on the screen at the same
time, in the same channel. When the Tare button is pressed, the instrument will subtract the current pres-
sure reading (the tare pressure) so that the indicator will display zero. Subsequent deviations in pressure
will be relative to the tare pressure.
Figure 6.4.1.7 - Tare Button
Pressing the tare button again will deactivate the tare and change the pressure indication back to the
reading corresponding to the calibrated output of the transducer. An active tare will revert to a deacti-
vated state after a power cycle.
Tare button,
active.
