Chapter 5 Settings
138
Item
Setting
*1
Details
If curved cutting lines become crooked, set to
"SLOW" to reduce the cutting speed on curved line
segments.
Up height
[UP HIGHT]
50%, 75%, 100% Sets the height when the tool is raised.
The height to which the tool is raised from the down
position is specified as a percentage of the
approximate stroke. A smaller height setting allows
faster cutting.
Set a larger up height in cases where there is a risk of
the ★cutter blade☆ damaging the sheet due to the
thickness of the sheet or the sheet lifting up.
NETWORK - Sets the network address. The machine must be
restarted to enable this setting.
"Configuring the Network Settings
[NETWORK]"(P. 122)
Event Mail - An email can be sent to a specified email address
when an event (e.g., cutting start, cutting end, and
abort) occurs. The machine must be restarted to
enable this setting.
"Event Email Function Settings [EVENT
MAIL]"(P. 124)
R.CONTRL - Enabling remote control allows the machine to be
operated remotely using without having to use the
operating panel on the machine. "Operating the
Main Unit Panel Remotely [R.CONTRL]"(P. 118)
Copy settings
[CONFIG COPY]
- Copies settings to the settings of another user.
"Copying Settings from Other User Settings
[CONFIG COPY]"(P. 129)
Setup Reset
[SETUP RESET.]
- Resets the details set.
"Restoring Default Settings [SETUP
RESET]"(P. 129)
*1. The default settings are shown underlined.
l
Command (MGL-Ic1/MGL-IIc) selection [COMMAND]
• Altering the command using [COMMAND] clears the receive buffer contents.
• When set to "AUTO", correct cutting results may not be achieved with large data sizes, for example. If
this occurs, change the setting to the command name (MGL-Ic1 or MGL-IIc).
• When set to "AUTO", cutting starts using the command detected by the machine once data has been
received from the computer. If [ERROR 16 AUTO I/F] appears after data has been received, this
indicates automatic detection failed.
If this occurs, set the command name (MGL-Ic1 or MGL-IIc) allowing correct cutting.
• The command automatically detected in "AUTO" remains effective until data is cleared "Aborting
Cutting (Data Clear)"(P. 74)) or the sheet is reloaded.
l
CUT MODE
Select "High Quality" when cutting the following data:
• 10 mm characters or smaller
• Data containing many sharp edges
• Fine cutting data This involves a risk of jagged cut lines if data is overly complex. In such cases, the lines
can be smoothed by changing the setting to "HIGHspd".
To Next Page
