1-4-2. Rear face
Name Function
1F ink station This station houses up to six ink cartridges.
2 Clamp lever It is made to go up-down the pinch roller for holding medium.
3 Roll holder Roll holder is inserted in the right and left core of roll medium to hold
the roll medium. The roll holder is applicable to diameter of medium
cores with 2 and 3 inches.
4 Paper roll setting bar This bar facilitates a paper roll to be set in position.
5 Ink cartridge Each cartridge contains ink of a specific color.
6R ink station This station houses up to six ink cartridges.
