5-1. Disassembly and assembly
5-1-1. Front cover assy., Y cover, SR cover, YR cover and Right cover
[Tools to be used]
• Phillips screwdriver (No. 2 for M3 to M5)
[Disassembling procedure]
1) Move the left front cover pin and then pull out the front cover.
2) Remove the screw (B3 x 6Ni), then remove the Y cover.
3) Remove the SR cover.
4) Remove the screw (B3 x 6Ni), then remove the YR cover.
• Before removing the YR cover, be sure to remove the cable because the cable of the
front cover sensor assembly is clamped on the back of the YR cover.
5) Remove the screw (B4 x 10Ni), then remove the right cover.
[Assembling procedure]
• Assembly is reverse of disassembly.
