– 4.59 –
4-5. #PARAMATER items
4-5-1. SYSTEM PARAMETER
[Function]
System parameter values are changed.
[System parameters list]
No. Indication Set value Description Remarks
0 COMP.X 0
1 COMP.Y 44
2R GRIP 0
3L GRIP 0
4 CAPpodY 20
5 CAPposZ 0
6 WIPposY 0
7 WIPposZ 35
8 STlower 0
9 CUTposi 0
10 EDGE LV 50
11 H12dist 252
12 H13dist 640
13 H35dist 640
14 H57dist 640
15 H24dist 640
16 H46dist 640
17 H68dist 640
18 PULLpos 25
19 Hdhight 0
Mechanical correction X
(in increments of 0.1 mm 500 mm – actual measured value)
Mechanical correction Y
(in increments of 0.1 mm 500 mm – actual measured value)
Adjustment of dead space on the right-hand side of the paper
(in increments of 0.1 mm 25mm - actual measured value)
Adjustment of dead space on the left-hand side of the paper
(in increments of 0.1 mm 5mm - actual measured value)
Adjustment of capping Y position (in increments of 0.1 mm)
Adjustment of capping Z position (in increments of 0.1 mm)
Adjustment of wiping Y position (in increments of 0.1 mm)
Adjustment of wiping Z position (in increments of 0.1 mm)
(in increments of 1 step)
Adjustment X of the medium cutting position
(in increments of 0.1 mm)
Medium edge detection level (Unit: %)
Distance between head 1/nozzle row A and head 2/nozzle row A
Distance between head 1/nozzle row A and head 2/nozzle row A
Distance between head 1/nozzle row A and head 2/nozzle row A
Distance between head 1/nozzle row A and head 2/nozzle row A
Distance between head 1/nozzle row A and head 2/nozzle row A
Distance between head 1/nozzle row A and head 2/nozzle row A
Distance between head 1/nozzle row A and head 2/nozzle row A
Idle suction position (in increments of 0.1 mm)
Reference head height
Adjustment of range
accuracy
If the system parameter
value is incrased:
Length of a pattern
plotted will be increased.
Adjustment value for
edge adjustment
If the system parameter
value is increased:
Dead space will be
reduced.
Adjustment value for
capping position
Adjustment value for
wiping position
Adjustment value in the
X-direction when cutting
If the system parameter
value is increased:
Remaining portion of the
paper after cutting will
become larger.
Edge detection level
when the medium width
is detected
