– 4.13 –
4-3-3. HEAD WASH
[Function]
The ink that has been filled is ejected, and the tube, damper and head are cleaned with a
washing fluid. This process is normally carried out prior to shipment from the factory
[Operation]
1) Select the ADJUSTMENT.
Press the
ENTER
key.
2) Press the
FUNCTION
key to select the “
WASH.”
Press the
ENTER
key.
3) Select the target head using the
or
key.
Specify the target head using the
ENTER
key.
4) Detach the ink cartridge from the head
selected.
The ink that has been filled is ejected to the waste
ink tank.
5) When the display shown at left appears, set the
cleaning tool.
Cleaning fluid is suctioned up.
6) When the display shown at left appears,
remove the cleaning tool.
Suck in air.
7) When the display shown at left appears, set the
cleaning tool.
Cleaning fluid is suctioned up.
8) When the display shown at left appears,
remove the cleaning tool.
The waste ink tank discharges the cleaning fluid
sucked.
FUNCTION
# ADJUST < ENT >
# ADJUST
WASH < ent >
WASH
SELECT : ALL
WASH
SELECT : FRONT
WASH
SELECT : REAR
WASHING
REMOVE CARTRIDGE
WASHING
SET CLEAN TOOL
WASHING
REMOVE TOOL
WASHING
SET CLEAN TOOL
WASHING
REMOVE TOOL
