– 4.28 –
4-3-13. MEDIA COMP2
[Function]
Corrects the amount of media feed at the time of plotting.
The correcting values are stored under the system parameters No. 20.
Make this adjustment only if a problem occurs when the media is normally set and
the folowing pattern is plotted using a combination of MIMAKI-brand Grossy White
PET(SPC-0111)and MIMAKI-brand colorant ink.
Reason : This adjustment changes the reference value for media correction. With this
change, the four types of [SET UP - MEDIA COMP.] for the user are all changed and
therefore the user needs re-adjustment.
The image shown at left is an
image when the circled section
above is observed with a scope.
Make adjustment so that
the 2-pass dots are shot
between 1-pass dots.
Good sample Bad sample
- adjustment + adjustment
* Since only the feed direction (X direction) is adjusted, the hatched dot pattern may not
result.
