– 4.20 –
4-3-7. CAPPING
[Function]
Capping position is adjusted. (Refer to [6-2-2. Adjustment of the station position] P.6-4)
The adjustment value is stored under the system parameter No. 4 to No.8.
[Operation]
1) Select the ADJUSTMENT.
Press the
ENTER
key.
2) Select the “CAPPING” pressing the
FUNCTION
key.
Press the
ENTER
key.
3) Check the head height.
If it is low, select YES; otherwise, select NO.
• Do not select YES if the head height
is not high. Doing so may disable
correct value display when checking
the head height.
4) Adjust the bottom position using the
or
key.
Press the
ENTER
key.
5) Adjust the Cap position using the
or
key.
Press the
ENTER
key.
6) Adjust the Cap height using the
or
key.
Press the
ENTER
key.
7) Adjust the Wiper position using the
or
key.
Press the
ENTER
key.
8) Adjust the Wiper height using the
or
key.
When you press the
ENTER
key, the setting
is registered and Capping executed.
9) Press the
key to exit from the
function.
FUNCTION
# ADJUST < ENT >
# ADJUST
CAPPING < ent >
HEAD height LOW?
NO < > YES
# CAPPING
LOWER POS. = ∗ ∗ ∗
# CAPPING
CAP POS. = ∗ . ∗
# CAPPING
CAP HEIGHT = ∗ . ∗
# CAPPING
WIPER POS. = ∗ . ∗
# CAPPING
WIPER height = ∗ . ∗
