4-4-5. Y SERVO
[Function]
Continuous outward/inward travel is executed in terms of the Y-direction for the purpose of
durability test.
This test can be executed without placing a media on the plotter.
• Execute the test with speed, acceleration and traveling amount set to the initial val-
ues. If they are excessively increased, the plotter can break.
[Operation]
1) Select the TEST.
Press the
ENTER
key.
2) Select the “Y SERVO” pressing the
FUNCTION
key.
Press the
ENTER
key.
3) Press the
ENTER
key twice without
changing the set value.
Now, the screen changes over to permit the setting
of a traveling amount in the Y-direction.
4) Press the
ENTER
key without changing the
set value.
The aging in the Y-direction starts.
5) Press the
key to interrupt the
operation.
FUNCTION
# TEST < ENT >
# TEST
Y SERVO < ent >
# Y SERVO
Y : S = ∗ ∗ ∗ A = ∗ . ∗ ∗
# Y SERVO
Y = ∗ ∗ ∗ ∗
# TEST
Y SERVO < ent >
