MIMAKI JV4-180 - Page 143

-5.13-
to Slider PCB assy.
to Slider PCB assy.
Damper holder
Print head
P2 x 8SMW
Head bracket
P4 x 12SMW
B3 x 10Bk
Angle spring
Adjusing spring
Adjusing spring
Head adjusing screw
Adjusing spring
Adjuster
Head adjusing
screw
Head adjusing
screw
B3 x 10Bk
Adjuster
Angle spring
Print head
P2 x 8SMW
Damper holder
