– 4.36 –
5) Select the plotting length in the X and Y-
direction using the
or key and press
the
ENTER
key.
Length setting: 10mm to the sheet width
(in increments of 10mm steps)
6) Select the color to plot.
Shift the cursor using the
or key to select
the color to be used.
Press the
or key ttto select wheter the
color is drawned or not.
7) At this time it is now ready for the
drawing.Press the
ENTER
key to start
drawing.
When the device is ready for plotting, the
followings can be setted.
: shift the origin.
REMOTE/LOCAL
: select the head used and the
high-speed scan.
Plotting can be aborted by pressing the
key.
8) After the completion of the plotting, press the
key in repetition to return the
layers of screens one by one to permit the
conditions to be changed.
# CHK PATTERN
PATTERN : PLOT
# CHK PATTERN
X = 10 Y = ∗ ∗ ∗ ∗
# CHK PATTERN
COLOR : KCMYcm
# CHK PATTERN
INK TYPE : Pigcm
( Select several)
