Mindray M5 User Manual

System Introduction
4-8
No English
Name
Name
Description
Function
25 Clear Clear Press to clear the comments or measurement
calipers on the screen.
26 Info Patient
information
Press to enter the [Patient Info] screen.
27 Exam Exam type Press to switch between exam types.
28 Review Review Press to review the image files stored.
29 End Exam End exam Press to end an exam.
30 Body Mark Body mark Press to enter or exit the Body Mark status.
31 Cine Cine review Press to enter or exit the Cine Review status.
32 Zoom Zoom Press to enter or exit the Zoom status.
33 Back Return or delete Press to return to the previous operation or
delete the previous item.
34 Change Change Press to toggle between calipers within the
same measurement.
35 Measure Measure Press to enter or exit the application
measurement mode.
36 Caliper Caliper Press to enter or exit the general measurement
mode.
37 Set Set Press to confirm an operation, same as the
left-button of the mouse.
38 / Trackball Roll the trackball to move the cursor position.
39 / Multifunction
knob
Rotate to adjust image parameters or comment
arrows. Or when the cursor is hidden, press to
show the cursor.
40 B / Press to enter the B mode
41 Dual / Press to enter the Dual mode from another
mode;
Press to switch between the two display
windows in the Dual mode.
42 iTouch / Rotate to increase or decrease the image gain;
press to optimize the image, serving as a
one-key optimization.
43 Color / Press to enter the Color mode.
44 Power / Press to enter the Power mode.
45 CW / Press to enter the CW mode.
46 Update / z Press to change the currently active
window in B+M or PW mode.
z Press to start or end image capture In
Smart3D or iScape mode.
47 PW / Press to enter the PW mode.
