9−4−5. Data format
(1) Command mode
1
Reading out the load data(Host→CSD−701B)
Command No.
Operation
21 Reading out the TRACK data
22 Reading out the PEAK data
Return(CSD−701B→Host)
2 4 6 8 10 12 14
@ 0 0 2 2 Terminator
Load data
Sign of load data
Command No.
ID No.
00〜31
D The comparative data enters from the right end.
D When the data is minus, “−”sign and when plus, “＋” sign is added.
D The sign data perform zero suppress.
D When the decimal point is set with the F−56 and at the same time the decimal
point is determined with the F−01, it will be added to the specified position.
D The message will be output at the time of overload.
D The empty sections are all spaces.
2468101214
@ 0 0 2 2 − 1 2 3 Terminator
2468101214
@ 0 0 2 2 ＋ 0 . 1 2 3 Terminator
2468101214
@ 0 0 2 2 ＋ O L Terminator
2468101214
@ 0 0 2 2 − O L Terminator
ID No.
00〜31
ID No.
00〜31
ID No.
00〜31
ID No.
00〜31
246
@ 0 0 2 2 Terminator
Command No.
ID No.
00〜31
