Reading−out the comparative data (Host→CSD−701B)
Command No.
Operation
31 Reading out S1 data
32 Reading out S2 data
Return(CSD−701B→Host)
2 4 6 8 10 12 14
@ 0 0 3 1 Terminator
Command No.
Sign
Setting value
ID No.
00〜31
D The comparative data enter from the right end.
D When the data is minus, “−”sign and when plus, “＋” sign is added.
D The sign data perform zero suppress.
D When the decimal point is set with the F−56 and at the same time the decimal
point is determined with the F−01, it will be added to the specified position.
D The empty sections are all spaces.
3
Writing comparative data (Host→CSD−701B)
2 4 6 8 10 12 14
@ 0 0 6 1 Terminator
Command No.
Sign
Set value
ID No.
00〜31
Command No.
Operation
61 Writing S1 data
62 Writing S2 data
Return(CSD−701B→Host)
24681012141
6
@ 0 0 6 1 Terminator
Command No.
Sign
Set value
ID No.
00〜31
D The comparative data enters from the right end.
D The setting range is within −99 999 to 99 999.
D Don’t add a decimal point.
246
@ 0 0 3 1 Terminator
Command No.
ID No.
00〜31
