129
Inform Minebea about the contents of
failure and situation at site in details.
13
Connected correctly.
Connect correctly by referring to the paragraph 9−4.
Use the command/data correctly by referring to
the paragraph 9−4.
Set the Yes to No of flow control for host.
NO
YES
NO
YES
NO
YES
YES
NO
Baud rate and so on
are set correctly.
Setting for the
command/data are correct.
Flow control
is specified by the
host.
ID Nos. are set
correctly.
Set the ID Nos. correctly by conforming to the
paragraph 8 and 9−4.
NO
YES
Set the following items correctly by conforming to the
specifications for the host.
・F−52 Setting the baud rate
・F−53 Setting the data bit length and the parity
・F−54 Setting the stop bit
・F−55 Setting terminator
(R efer to the paragraph 8 and 9−4.)
To Next Page
