128
Inform Minebea about the contents of
failure and situation at site in details.
12
Connecting is good.
Connect correctly by referring to the paragraph 9−3.
Use the command/data correctly by referring to the
paragraph 9−3.
Set the following items correctly by conforming to the
specifications for the host.
・F−52 Setting the baud rate
・F−53 Setting the data bit length and the parity
・F−54 Setting the stop bit
・F−55 Setting terminator
(R efer to the paragraph 8 and 9−3.)
Set the Yes No of flow control for host to.
NO
YES
NO
YES
NO
YES
YES
NO
Baud rate and so on
are set correctly.
Setting for the
command/data are
correct.
Flow control is
specified by the host.
Select the output target in the stream mode.
・F−50 Setting in the Operation mode
・F−51 Setting the output target in the Stream
mode
(R efer to the paragraph 8 and 9−3.)
NO
YES
Intended value
is not transmitted in the
stream mode.
To Next Page
