127
Inform Minebea about the contents of
failure and situation at site in details.
11
Set correctly.
Connect with the external instrument by
referring to the paragraph 9−2
Select the target of BCD output.
・F−40 Setting the target of BCD output
(R efer to the chapter 8.)
Adjust the setting related with BCD output to the
specifications for external connecting instruments.
・F−41 Setting the output logic for BCD data
・F−42 Setting the output logic for BCD
polarity
・F−43 Setting the output logic for BCD flag
・F−44 Setting the output logic for P.C.
・F−45 Setting the P.C. width
(R efer to the chapter 8.)
Set the HOLD input open.
NO
YES
NO
YES
NO
YES
YES
NO
Other than the BCD
is output.
Intended value
isn’t output.
BCD output will
not vary.
To Next Page
