Minebea CSD-701B - Page 40

27
Procedures
8
Press the  key.
The load display will show “0.0000”, and the
digit of 10
0
will flash on and off. In case that
calibration has completed already, the registered
output value of load cell at that time will be
displayed.
Set the output value for load cell with the initial
load application with the right keys.
 Though the number of digits has not
prepared in the ”Inspection data” for load
cell so many as shown in the right figure,
extra
digits
are
necessary
for
the
 key ：Set value carry key
 key ：Set value inclement key

ke
y
：
Se
t
value initialization ke
y
8
extra
digits
are
necessary
for
the
compensation with the standard point at
internal of the instrument.
In case of actual setting, insert “0”, into the
extra digits.
As for the value for extra digit, when tare
compensation and fine adjustment on load
are applied, it will be rewritten as a
compensated value automatically.
Setting range for the output of load cell is
from −0.3 mV/V to 2.400 0 mV/V.
 It can be increased continuously by the
continuity press of the key.

key
：
Set
value
initialization
key
9
Press the  key.
The load display will show “S MV”.
