7. Usage
MiR250 Hook Integrator Manual (en) 12/2023 - v.3.0 ©Copyright 2021–2023: Mobile Industrial Robots A/S. 107
Figure 7.6 Front view of a cart (left), and side view of a cart (right).
Pos. Description Pos. Description
A Cart width: between 400 mm and
1500 mm
B Cart length: between 500 mm
and 2400 mm
C Cart height: maximum 1800 mm D Locked wheels offset: the
locked wheels offset is the
distance from the gripping
point of the cart to the locked
wheels axis.
Table 7.2 Identification of the cart dimensions in Figure 7.6
For more information, see "Cart specifications" on page94.
