112
If after hours
specified.
The after hours and night time
alarm level 3 sensitivity of the
sensor. Displays a combo with sensitivity in appropriate units for
the device type. Optional if Lvl2 specified.
Yes
The text of the tag, in two 20 character fields, representing the
two lines displ
ayed on the front panel when an alarm occurs,
etc. The two fields are concatenated, trimmed of trailing spaces
and saved on the database.
Alternate
Tag (Line 1
and Line 2
Yes
Specifies tags to be used on displays where Alternate Tags is
specified. See
Main Display / LCD Annunciator.
The primary tags
will be used on all other displays. The alternate tags will typically
be in a different language, but the characters must be supported
by the same code page. For example, the primary tags could be
in Arabic and used on most displays, but other displays could be
showing English.
Flag Columns
There are up to four Flag columns (F1, F2, F3 and F4) for flags of various types.
• AR - Auxiliary Reset required - used on Relay
• BU - Back Up amplifier - used on audio controller. Designates the amplifier as
the back up. It must be of sufficient power to substitute any of the other
configured amplifiers. The back up amplifier can only accept correlations to
status LEDs, trouble LEDs and UDACT groups.
• ER - Enable Required - used on switches for security (code or key)
• GA - 2nd Stage Alarm - in two stage system or to return the supervised signal to
EVAC rate after code is completed in coded System
• NB - Relay is Non Bypassable when 'Relay disconnect' is used or when an "Aux
Disc" switch is pressed.
• NC - Not coded - used on supervised outputs i.e. Strobe to keep the strobe
operating until Reset (even after Code has ended)
• ND - No Display - indicates that activation of this input device is not to be
displayed in the queue. A similar flag applies to Input Zones. By default, devices
do not have the flag set and zones do.
• NS - Non Silenceable - used on inputs and supervised Outputs
