152
I
NSTALLING, POWERING, CONNECTING AND REGISTERING TERMINALS
CHAPTER 4 INSTALLATION
NOTE: The total length of the cables from the communication server to the system phone must not be less
than 10 m.
Terminal selection
Two system phones can be connected to a DSI interface (DSI-AD2 only). The system can only differen-
tiate the two system phones by the position of the address switch on the phone. The following settings
are possible (TSD = Terminal Selection Digit):
• TSD1
• TSD2
NOTE: In the following cases Not Configured is displayed along with the node number, the slot number
and the port number. In this state the system phone is not ready for operation:
– A terminal has been created at the connected port, but the address selection switch is incor-
rectly set.
– No terminal has yet been created at the connected port.
User allocation
In the configuration each terminal is assigned to a user or a free seating pool. If a terminal has been
created at the connected port and the address selection switch is correctly selected but no user or free
seating pool is allocated to the terminal, the system phone display reads No Number and indicates the
terminal ID. In this state the system phone is not ready for operation.
Terminal type
The terminal type is specified along with the configuration of the system. Lines are also assigned to the
line keys there.
NOTE: If the terminal type configured is incorrect, the system phone display shows the warning Wrong
phone type. In this situation, although the system phone can be used for basic telephone operations,
none of the added features will be available. The terminal type must be entered via WebAdmin or on the
terminal via login to the system configuration.
Carrying out a logon on the system phone: Long keypress (long click) on a function key. Set new phone
type appears next. Confirm with Foxkey Yes.
MiVoice 5361 / 5370/ 5380
These IP system phones can be both desktop-mounted and wall-mounted.
Mounting the phone
The following points are described in detail in the User’s Guides for MiVoice 5361 / 5370 / 5380:
• Set-up as a desk phone (choice of two different set-up angles)
• Wall mounting
• Connecting one or more MiVoice M530 or MiVoice M535 expansion key modules.
• Connection of a headset to DHSG standard.
NOTE: To prevent any damage to the phone, always disconnect the phone from the power supply
first before connecting a headset to DHSG standard.
Mounting the Bluetooth module
