Mitsubishi F700 Series User Manual

124
Function assignment of external
terminal and control
14 114 FDN PID lower limit
Output when the feedback value falls below
the lower limit of PID control.
Pr. 127 to Pr. 134,
Pr. 575 to Pr. 577
25615 115 FUP PID upper limit
Output when the feedback value rises above
the upper limit of PID control
16 116 RL
PID forward/reverse
rotation output
Output when forward rotation is performed in
PID control.
17  MC1
Electronic bypass MC1
Used when the bypass-inverter switchover
function is used.
Pr. 135 to Pr. 139,
Pr. 159
28718  MC2 Electronic bypass MC2
19  MC3 Electronic bypass MC3
25 125 FAN Fan fault output Output at the time of a fan alarm. Pr. 244 296
26 126 FIN
Heatsink overheat
pre-alarm
Output when the heatsink temperature
reaches about 85% of the heatsink overheat
protection operation temperature.
 336
45 145 RUN3
Inverter running and
start command is ON
Output when the inverter is running and start
command is ON.
 126
46 146 Y46
During deceleration at
occurrence of power
failure
Output when the power failure-time
deceleration function is executed.
(retained until release)
Pr. 261 to Pr. 266 151
47 147 PID
During PID control
activated
Output during PID control.
Pr. 127 to Pr. 134,
Pr. 575 to Pr. 577
256
48 148 Y48 PID deviation limit
Output when the absolute value of deviation
exceeds the limit value.
Pr. 127 to Pr. 134,
Pr. 241, Pr. 553, Pr.
554, Pr. 575 to Pr.
577, C42 to C45
256
49 149 Y49
During pre-charge
operation
Output during the pre-charge operation.
Pr. 127 to Pr. 134,
Pr. 241, Pr. 553,
Pr. 554,
Pr. 575 to Pr. 577,
Pr. 753 to Pr. 769,
C42 to C45
256,
270
50 150 Y50
During second pre-
charge operation
256,
270
51 151 Y51 Pre-charge time over
Output when the pre-charged time exceeds
the time set in Pr.764 or Pr.769.
256,
270
52 152 Y52
Second pre-charge
time over
256,
270
53 153 Y53 Pre-charge level over
Output when the pre-charged amount
exceeds the set level in Pr.763 or Pr.768.
256,
270
54 154 Y54
Second pre-charge
level over
256,
270
64 164 Y64 During retry Output during retry processing. Pr. 65 to Pr. 69 154
67 167 Y67 During power failure
Output during output shutoff due to power
failure or under voltage.
Pr. 57 150
70 170 SLEEP
PID output
interruption
Output when the PID output interruption
function is executed.
Pr. 127 to Pr. 134,
Pr. 575 to Pr. 577
256
71

RO1
Commercial-power
supply side motor 1
connection RO1
Used when using advanced PID control
(pump function).
Pr. 575 to Pr. 591 277
72

RO2
Commercial-power
supply side motor 2
connection RO2
73

RO3
Commercial-power
supply side motor 3
connection RO3
74

RO4
Commercial-power
supply side motor 4
connection RO4
75

RIO1
Inverter side motor 1
connection RIO1
76

RIO2
Inverter side motor 2
connection RIO2
77

RIO3
Inverter side motor 3
connection RIO3
78

RIO4
Inverter side motor 4
connection RIO4
Setting
Signal
Name
Function Operation
Related
Parameters
Refer
to Page
Positive
Logic
Negative
Logic

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
