Communication operation and setting
4
PARAMETERS
(3) Communication operation presence/absence and data format types
 Data communication between the computer and inverter is made in ASCII code (hexadecimal code).
 Communication operation presence/absence and data format types are as follows:
Data writing format
Communication request data from the computer to the inverter 1)
Reply data from the inverter to the computer 3) (No data error detected)
Reply data from the inverter to the computer 3) (With data error)
Symbol
Operation
Run
Command
Running
Frequency
Multi
command
Parameter
Write
Inverter
Reset
Monitor
Parameter
Read
1)
Communication request is sent to the
inverter in accordance with the user
program in the computer.
A, A1 A A2 A A B B
2)
Inverter data processing time Present Present Present Present Absent Present Present
3)
Reply data from the
inverter (Data 1) is
checked for error)
No error
*1
(Request accepted)
CCC1 *3 CC *2
E, E1,
E2, E3
E
With error.
(Request rejected)
DDD DD *2 DD
4)
Computer processing delay time 10ms or more
5)
Answer from
computer in response
to reply data 3)
(Data 3) is checked
for error)
No error
*1
(No inverter
processing)
Absent Absent
Absent
(C)
Absent Absent
Absent
(C)
Absent (C)
With error
(Inverter re-
outputs 3))
Absent Absent F Absent Absent F F
*1 In the communication request data from the computer to the inverter, 10ms or more is also required after "no data error (ACK)". (Refer to
page 217)
*2 The inverter response to the inverter reset request can be selected. (Refer to page 222)
*3 At mode error, and data range error, C1 data contains an error code. (Refer to page 226) Except for those errors, the error is returned with data
format D.
Format
Number of Characters
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
A
ENQ
*1
Inverter
station
number
*2
Instruction
code
*3
Data
Sum
check
*4
A1
ENQ
*1
Inverter
station
number
*2
Instruction
code
*3
Data
Sum
check
*4
A2
ENQ
*1
Inverter
station
number
*2
Instruction
code
*3
Send
data
type
Receive
data
type
Data1 Data2
Sum
check
*4
Format
Number of Characters
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
C
ACK
*1
Inverter
station
number
*2
*4
C1
STX
*1
Inverter
station
number
*2
Send
data
type
Receive
data
type
Error
code 1
Error
code 2
Data1 Data2
ETX
*1
Sum
check
*4
Format
Number of Characters
1 2 3 4 5
D
NAK
*1
Inverter
station
number
*2
Error
code
*4
*1 Indicate a control code
*2 Specify the inverter station numbers between H00 and H1F (stations 0 to 31) in hexadecimal.
*3 When Pr.123 and Pr.337 (Waiting time setting) 9999, create a communication request data without "waiting time" in the data format. (The
number of characters decreases by 1.)
*4 CR, LF code
When data is transmitted from the computer to the inverter, codes CR (carriage return) and LF (line feed) are automatically set at the end of a
data group on some computers. In this case, setting must also be made on the inverter according to the computer. Whether the CR and LF
codes will be present or absent can be selected using Pr. 124 PU communication CR/LF selection.

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
