248
Communication operation and setting
BINARY INPUT
*1 R: Read only W: Read/Write (Commandable values not supported) C: Read/Write (Commandable values supported)
BINARY OUTPUT
*1 R: Read only W: Read/Write (Commandable values not supported) C: Read/Write (Commandable values supported)
*2 Available regardless of operation mode, operation command source and speed command source.
Object
Identifier
Object Name
Present Value
Access Type
*1
Description
(0: Inactive
1: Active)
0 Terminal STF R Represents actual input of terminal STF.
1 Terminal STR R Represents actual input of terminal STR.
2 Terminal AU R Represents actual input of terminal AU.
3 Terminal RT R Represents actual input of terminal RT.
4 Terminal RL R Represents actual input of terminal RL.
5 Terminal RM R Represents actual input of terminal RM.
6 Terminal RH R Represents actual input of terminal RH.
7 Terminal JOG R Represents actual input of terminal JOG.
8 Terminal MRS R Represents actual input of terminal MRS.
9 Terminal STOP R Represents actual input of terminal STOP.
10 Terminal RES R Represents actual input of terminal RES.
11 Terminal CS R Represents actual input of terminal CS.
100 Terminal RUN R Represents actual output of terminal RUN.
101 Terminal SU R Represents actual output of terminal SU.
102 Terminal IPF R Represents actual output of terminal IPF.
103 Terminal OL R Represents actual output of terminal OL.
104 Terminal FU R Represents actual output of terminal FU.
105 Terminal ABC1 R Represents actual output of terminal ABC1.
106 Terminal ABC2 R Represents actual output of terminal ABC2.
Object
Identifier
Object Name
Present Value
Access Type
*1
Description
(0: Inactive
1: Active)
0 Terminal RUN CMD C
Controls actual output of terminal RUN.
Available when Pr. 190 RUN terminal function selection = "82 or 182".
*2
1 Terminal SU CMD C
Controls actual output of terminal SU.
Available when Pr. 191 SU terminal function selection = "82 or 182".
*2
2 Terminal IPF CMD C
Controls actual output of terminal IPF.
Available when Pr. 192 IPF terminal function selection = "82 or 182".
*2
3 Terminal OL CMD C
Controls actual output of terminal OL.
Available when Pr. 193 OL terminal function selection = "82 or 182".
*2
4 Terminal FU CMD C
Controls actual output of terminal FU.
Available when Pr. 194 FU terminal function selection = "82 or 182".
*2
5 Terminal ABC1 CMD C
Controls actual output of terminal ABC1.
Available when Pr. 195 ABC1 terminal function selection = "82 or 182".
*2
6 Terminal ABC2 CMD C
Controls actual output of terminal ABC2.
Available when Pr. 196 ABC2 terminal function selection = "82 or 182".
*2
