375
Outline dimension drawings
7
SPECIFICATIONS
FR-F740-07700, 08660-EC
DC reactor supplied
(Unit: mm)
3-φ12 hole
R/L1
S/L2
T/L3
N/-
P1
P/+
UW
V
790
440
4.5 4.5
185
222 194
1300
1330
315
12
315
E
P
P1
P1
P
75
40
40
500 10
455 10
220
195
Rating plate
2-M8 eye nut
2-terminal
4- 15 hole
* Remove the eye nut after installation of the product.
Earth (ground) terminal
(for M8 screw)
Within 250
Within 235
4-installation hole
(for M10 screw)
DC reactor Model
Mass
(kg)
FR-HEL-H400K (FR-F740-07700-EC) 50
FR-HEL-H450K (FR-F740-08660-EC) 57
