Parameter List
Parameter list
4
PARAMETERS
Output terminal function assignment
190
RUN terminal function selection
0 to 5, 7, 8, 10 to 19, 25,
26, 45 to 54, 64, 67,
70 to 79, 82, 85, 90 to
96, 98, 99, 100 to 105,
107, 108, 110 to 116,
125, 126, 145 to 154,
164, 167, 170 to 179,
182, 185, 190 to 196,
198, 199, 9999
1 0 123
191
SU terminal function selection 1 1 123
192
IPF terminal function selection 1 2 123
193
OL terminal function selection 1 3 123
194
FU terminal function selection 1 4 123
195
ABC1 terminal function selection
0 to 5, 7, 8, 10 to 19, 25,
26, 45 to 54, 64, 67,
70 to 79, 82, 85, 90, 91,
94 to 96, 98, 99,
100 to 105, 107, 108,
110 to 116, 125, 126,
145 to 154, 164, 167,
170 to 179, 182, 185,
190, 191, 194 to 196,
198, 199, 9999
1 99 123
196
ABC2 terminal function selection 1 9999 123
Multi-speed
setting
232
to
239
Multi-speed setting (8 speed to 15
speed)
0 to 400Hz, 9999 0.01Hz 9999 86

240
Soft-PWM operation selection 0, 1 1 1 164

241
Analog input display unit switchover 0, 1 1 0 172

242
Terminal 1 added compensation
amount (terminal 2)
0 to 100% 0.1% 100% 170

243
Terminal 1 added compensation
amount (terminal 4)
0 to 100% 0.1% 75% 170

244
Cooling fan operation selection 0, 1 1 1 296
Slip
compensation
245
Rated slip 0 to 50%, 9999 0.01% 9999 73
246
Slip compensation time constant 0.01 to 10s 0.01s 0.5s 73
247
Constant-power range slip
compensation selection
0, 9999 1 9999 73

250
Stop selection
0 to 100s,
1000 to 1100s, 8888,
9999
0.1s 9999 114

251
Output phase loss protection
selection
0, 1 1 1 157
Frequency compensation
function
252
Override bias 0 to 200% 0.1% 50% 170
253
Override gain 0 to 200% 0.1% 150% 170
Life check
255
Life alarm status display (0 to 15) 1 0 297
256
Inrush current limit circuit life display (0 to 100%) 1% 100% 297
257
Control circuit capacitor life display (0 to 100%) 1% 100% 297
258
Main circuit capacitor life display (0 to 100%) 1% 100% 297
259
Main circuit capacitor life measuring 0, 1 1 0 297

260
PWM frequency automatic switchover 0, 1 1 1 164
Function Parameters
Name Setting Range
Minimum
Setting
Increments
Initial
Value
Refer
to
Page
Customer
Setting

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
