Mitsubishi F700 Series User Manual

66
Parameter list
Free
parameter
888
Free parameter 1 0 to 9999 1 9999 303
889
Free parameter 2 0 to 9999 1 9999 303
Energy saving monitor
891
Cumulative power monitor digit
shifted times
0 to 4, 9999 1 9999 159
892
Load factor 30 to 150% 0.1% 100% 159
893
Energy saving monitor reference
(motor capacity)
0.1 to 55kW/
0 to 3600kW
*2
0.01/0.1kW
*2
SLD/LD value
of Applied
motor Capacity
159
894
Control selection during commercial
power-supply operation
0, 1, 2, 3 1 0 159
895
Power saving rate reference value 0, 1, 9999 1 9999 159
896
Power unit cost 0 to 500, 9999 0.01 9999 159
897
Power saving monitor average time 0, 1 to 1000h, 9999 1h 9999 159
898
Power saving cumulative monitor
clear
0, 1, 10, 9999 1 9999 159
899
Operation time rate (estimated value) 0 to 100%, 9999 0.1% 9999 159
Calibration parameters
C0
(900) *5
CA terminal calibration 144
C1
(901) *5
AM terminal calibration 144
C2
(902) *5
Terminal 2 frequency setting bias
frequency
0 to 400Hz 0.01Hz 0Hz 172
C3
(902) *5
Terminal 2 frequency setting bias 0 to 300% 0.1% 0% 172
125
(903) *5
Terminal 2 frequency setting gain
frequency
0 to 400Hz 0.01Hz 50Hz 172
C4
(903) *5
Terminal 2 frequency setting gain 0 to 300% 0.1% 100% 172
C5
(904) *5
Terminal 4 frequency setting bias
frequency
0 to 400Hz 0.01Hz 0Hz 172
C6
(904) *5
Terminal 4 frequency setting bias 0 to 300% 0.1% 20% 172
126
(905) *5
Terminal 4 frequency setting gain
frequency
0 to 400Hz 0.01Hz 50Hz 172
C7
(905) *5
Terminal 4 frequency setting gain 0 to 300% 0.1% 100% 172
Analog output
current calibration
C8
(930) *5
Current output bias signal 0 to 100% 0.1% 0% 144
C9
(930) *5
Current output bias current 0 to 100% 0.1% 0% 144
C10
(931) *5
Current output gain signal 0 to 100% 0.1% 100% 144
C11
(931) *5
Current output gain current 0 to 100% 0.1% 100% 144
PID control
 C42
(934) *5
PID display bias coefficient 0 to 500.00, 9999 0.01 9999 256
 C43
(934) *5
PID display bias analog value 0 to 300.0% 0.1% 20% 256
 C44
(935) *5
PID display gain coefficient 0 to 500.00, 9999 0.01 9999 256
 C45
(935) *5
PID display gain analog value 0 to 300.0% 0.1% 100% 256

986
Terminal 10 calibration for PTC
thermistor
4 to 6V, 8888, 9999 0.01V 5.00V 100
Function Parameters
Name Setting Range
Minimum
Setting
Increments
Initial
Value
Refer
to
Page
Customer
Setting

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
