M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
88
IB-1501269-J
[Installation dimension: FCU8-DX731 / FCU8-DX750 / FCU8-DX760 / FCU8-DX761 / FCU8-DX834]
(Note) The unit thickness of the fixed part with screws is 16.6mm.
Select the fixing screws having the length suitable for the thickness.
171±0.3
(5)
(4)
106±0.3
(4)
(5)
[mm]
4-M3 screw
116 (Unit outline)
179 (Unit outline)
